| Series | Description | Model |  Nominal Power(±10%) | Voltage Rating 电压范围 | Lumen (lm)(±10%) | Ra | Beam Angle | Life(H) | PF | Dimension（mm) | Cut-out（mm） | ||
| 30K | 40K | 65K | |||||||||||
| TH01 | 3W SMD | SJL-TH03-3 | 3W | 180-264V/AC | 210 | 220 | 220 | ≥70 | 38 | 15000 | 0.5 | Φ70x42 | Φ65 |
| 5W SMD | SJL-TH03-5 | 5W | 180-264V/AC | 320 | 330 | 350 | ≥70 | 38 | 15000 | 0.5 | Φ85x42 | Φ75 | |
| 7W SMD | SJL-TH03-7 | 7W | 180-264V/AC | 480 | 480 | 490 | ≥70 | 38 | 15000 | 0.5 | Φ95x42 | Φ80 | |
| 9W SMD | SJL-TH03-9 | 9W | 180-264V/AC | 620 | 620 | 630 | ≥70 | 38 | 15000 | 0.5 | Φ118x55 | Φ90 | |
